Item:9564P, 4-1/2" ANGLE GRINDER 10 AMP PADDLE SWITCH
Makita 9564P 4-1/2 Inch SJS Paddle Switch Angle Grinder
SJS™ Mechanical Clutch System Helps Prevent Motor and Gear Damage
FEATURES
- Powerful 10.0 AMP motor delivers more output and 10,500 RPM for the most demanding applications
- SJS™ technology is a mechanical clutch system that helps prevent motor and gear damage by allowing the drive shaft to slip if the wheel is forced to stop
- Larger cooling fan and blades pull more air through the motor to help maintain lower operating temperature
- Large flush-mount paddle switch with integrated lock-off tab for more comfortable operation
- Labyrinth construction seals and protects the motor and bearings from dust and debris for longer tool life
- “Clam-shell” gear box design for greater durability and easier servicing
- Spiral bevel gears for smoother rotations and a more efficient transfer of energy
- Zig-zag varnish protects the armature coil from dust and debris for longer motor life
- "Tool-less" wheel guard for more convenient adjustments
- Spring loaded metal sealed drive bearing is engineered to prevent dust and debris from penetrating drive bearing
- (1) Side Handle (153489-2)
- (1) 4-1/2" Tool-less Wheel Guard (135107-4)
- (1) Inner Flange (224399-1)
- (1) Lock Nut (193465-4)
- (1) Lock Nut Wrench (782424-9)
SPECIFICATIONS
Model No. | 9564P |
Wheel Diameter | 4-1/2" |
Amps | 10 |
No Load Speed | 10,500 RPM |
Spindle Thread | 5/8"-11 UNC |
Lock On | No |
Lock Off | Yes |
Grinder Switch Type | Body grip/paddle |
Overall Length | 12-1/8" |
Net Weight | 5.1 lbs. |
Shipping Weight | 6.5 lbs. |
UPC Code | 088381638432 |
Makita 9564P 4-1/2 Inch SJS Paddle Switch Angle Grinder
